LED find the + Anode and the - Cathode / DEL trouver le + Anode et le - Cathode
Electronic / Électronique

Cathode = Flat side / Côté plat

Anode = Lengthy pin / broche la plus longue

The light is emitted upwards and not on the side / La lumière est émise vers le haut et non sur le côté


      Forward voltage
drop typical (V)		 Viewing Angle Max forward
current (mA)		   Typical luminous
intensity
red_led_3mm.png Red 3mm diffused LED - 275mCd 2.1 60 25 275 mCd (@20mA)
red_led_3mm.png Red 3mm water clear LED - 25deg - 1000mCd 2.1 25 25 1000 mCd (@20mA
green_led_3mm.png Green 3mm diffused LED - 53mCd 2.1 60 25 35 mCd (@20mA)
green_led_3mm.png Green 3mm water clear LED - 25deg - 75mCd 2.1 25 25 50-100 mCd (@20mA)
yellow_led_3mm.png Yellow 3mm diffused LED - 125mCd 2.1 60 25 125 mCd (@20mA)
yellow_led_3mm.png Yellow 3mm water clear LED - 25deg - 1000mCd 2.1 25 25 1000 mCd (@20mA)
blue_led_3mm.png Blue 3mm diffused LED - 500mCd 3.1 60 25 500 mCd (@20mA)
blue_led_3mm.png Blue 3mm water clear LED - 25deg - 1750mCd 2.1 25 25 1500-2000 mCd (@20mA)
white_led_3mm.png White 3mm diffused LED - 700mCd 3.1 60 25 700 mCd (@20mA)
white_led_3mm.png White 3mm water clear LED - 25deg - 2750mCd 3.1 25 25 2000-3500 mCd (@20mA)
amber_led_3mm.png Amber 3mm water clear LED - 25deg - 1750mCd 2.1 25 25 1750 mCd (@20mA)
pink_led_4.8mm.png Pink 4.8mm water clear LED - 100deg - 700mCd 3.1 100 30 700 mCd (@20mA)
red_led_5mm.png Red 5mm diffused LED - 275mCd 2.1 60 25 275 mCd (@20mA)
red_led_5mm.png Red 5mm water clear LED - 25deg - 1150mCd 2.1 25 25 800-1500 mCd (@20mA)
green_led_5mm.png Green 5mm diffused LED - 35mCd 2.1 60 25 35 mCd (@20mA)
green_led_5mm.png Green 5mm water clear LED - 25deg - 1000mCd 2.1 25 25 800-1200 mCd (@20mA)
yellow_led_5mm.png Yellow 5mm diffused LED - 125mCd 2.1 60 25 125 mCd (@20mA)
yellow_led_5mm.png Yellow 5mm water clear LED - 25deg - 800mCd 2.1 40 25 600-1000 mCd (@20mA)
orange_led_5mm.png Orange 5mm diffused LED - 275mCd 2.1 60 25 275 mCd (@mA20)
white_led_5mm.png White 5mm diffused LED - 700mCd 3.1 60 25 700 mCd (@20mA)
white_led_5mm.png White 5mm water clear LED - 25deg - 2250mCd 3.1 25 25 1500-3000 mCd (@20mA)
blue_led_5mm.png Blue 5mm diffused LED - 500mCd 3.1 60 25 500 mCd (@20mA)
blue_led_5mm.png Blue 5mm water clear LED - 25deg - 1000mCd 3.1 25 25 800-1500 mCd (@20mA)
uv_led_5mm.png UV 5mm water clear LED - 15deg - 95mCd 3.4 15 30 95mCd (@20mA)
orange_led_5mm.png Amber 5mm water clear LED - 25deg - 900mCd 2.1 40 25 800-1000 mCd (@20mA)
red_led_10mm.png Red 10mm diffused LED - 350mCd 2.1 60 25 350 mCd (@20mA)
green_led_10mm.png Green 10mm diffused LED - 350mCd 2.1 60 25 350 mCd (@20mA)
yellow_led_10mm.png Yellow 10mm diffused LED - 350mCd 2.1 60 25 350 mCd (@20mA)
red_led_10mm.png Red 10mm diffused LED - 900mCd x10 2.1 60 25 900 mCd (@20mA)
green_led_10mm.png Green 10mm diffused LED - 1750mCd x10 3.1 60 25 1750 mCd (@20mA)
yellow_led_10mm.png Yellow 10mm diffused LED - 900mCd x10 2.1 60 25 900 mCd (@20mA)
white_led_10mm.png White 10mm diffused LED - 1750mCd x10 3.1 60 25 1750 mCd (@20mA)
Description Forward voltage
drop typical (V)		 Viewing Angle Max forward
current (mA)		 Typical luminous
intensity
red_led_5mm.png Red flashing 5mm water clear LED - 30deg - 3500mCd 3.0 - 5.0 30 20 3500 mCd (@20mA)
green_led_5mm.png Green flashing 5mm water clear LED - 30deg - 4000mCd 3.0 - 5.0 30 20 4000 mCd (@20mA)
yellow_led_5mm.png Yellow flashing 5mm water clear LED - 30deg - 3500mCd 3.0 - 5.0 30 20 3500 mCd (@20mA)
blue_led_5mm.png Blue flashing 5mm water clear LED - 30deg - 3500mCd 3.0 - 5.0 30 20 3500 mCd (@20mA)
white_led_5mm.png White flashing 5mm water clear LED - 30deg - 8400mCd 3.0 - 4.5 30 20 8400 mCd (@20mA)
yellow_led_5mm.png Yellow candle 5mm water clear LED - 30deg - 5800mCd 3.3 30 20 5800mCd (@20mA)
Description Forward voltage
drop typical (V)		 Viewing Angle Max forward
current (mA)		 Typical luminous
intensity
rgb_led_5mm.png Colour Changing 5mm diffused LED - 750mCd 2.7 - 5 30 40 (25 Ave) 600/1000/500 (R/G/B mCd)
rgb_led_5mm.png Colour Changing 5mm diffused LED - 540mCd 3.8 - 5 20 330/500/750 (R/G/B mCd)
rgb_led_10mm.png Colour Changing 10 mm diffused LED - 750mCd 2.7 - 5 30 40 (25 Ave) 600/1000/500 (R/G/B mCd)
rgb_led_5mm.png RGB 5mm water clear LED - 45deg - 2100mCd - common anode 1.9 - 2.5 (R)
2.9 - 3.5 (G)
2.9 - 3.5 (B)		 45 1500-2300 mCd (R)
2000-2700 mCd (G)
1500-2200 mCd (B)
rgb_led_5mm.png RGB 5mm water clear LED - 45deg - 2100mCd - common cathode 1.9 - 2.5 (R)
2.9 - 3.5 (G)
2.9 - 3.5 (B)		 45 1500-2300 mCd (R)
2000-2700 mCd (G)
1500-2200 mCd (B)
rgb_led_5mm.png Tri Colour 5mm diffused LED - 650mCd x25 2.1 30 30 750 mCd (R)
550 mCd (G)
red_led_5mm.png Red 5mm diffused LED - 80mCd - 5V x10 5.0 60 13 80 mCd (@20mA)
green_led_5mm.png Greeen 5mm diffused LED - 32mCd - 5V x10 5.0 60 13 32 mCd (@20mA)
yellow_led_5mm.png Yellow 5mm diffused LED - 32mCd - 5V x10 5.0 60 13 32 mCd (@20mA)
Description Forward voltage
drop typical (V)		 Viewing Angle Max forward
current (mA)		 Typical luminous
intensity
red_led_5mm.png Red 5mm water clear LED - 30deg - 1000mCd 1.85 30 30 1000 mCd (@20mA)
white_led_5mm.png White 5mm water clear LED - 15deg - 5000mCd 3.2 15 30 5000 mCd (@20mA)
blue_led_5mm.png Blue 5mm water clear LED - 15deg 3500mCd 3.2 15 30 3500 mCd (@20mA)
white_led_5mm.png White 5mm water clear LED - 140deg - 3000mCd 3.1 140 30 3000 mCd (@20mA)
green_led_5mm.png Green 5mm water clear LED - 30deg - 9500mCd 3.1 30 30 8000-11000 mCd (@20mA)
yellow_led_5mm.png Yellow 5mm water clear LED - 30deg - 9500mCd 2.2 30 30 8000-11000 mCd (@20mA)
red_led_5mm.png Red 5mm water clear LED - 30deg - 8500mCd 2.2 30 30 8000-11000 mCd (@20mA)
blue_led_5mm.png Blue 5mm water clear LED - 15deg - 9500mCd 3.1 15 30 8000-11000 mCd (@20mA)
green_led_5mm.png Green 5mm water clear LED - 15deg - 17500mCd 3.1 15 30 15000-20000 mCd (@20mA)
yellow_led_5mm.png Yellow 5mm water clear LED - 15deg - 17500mCd 2.2 15 30 15000-20000 mCd (@20mA)
red_led_5mm.png Red 5mm water clear LED - 15deg - 17500mCd 2.2 15 30 15000-20000 mCd (@20mA)
white_led_5mm.png White 5mm water clear LED - 30deg - 17500mCd 3.2 25-30 30 15000-20000 mCd (@20mA)
white_led_5mm.png White 5mm water clear LED - 15deg - 17500mCd 3.2 15 30 15000-20000 mCd (@20mA)
uv_led_5mm.png Sakuru (Lilac) water clear LED - 15deg - 8400mCd 3.1 15 20 8400mCd (@20mA)
white_led_3mm.png White 3mm water clear - 25deg - 12500mCd - x10 3.1 25 25 10000-15000 mCd (@20mA)
blue_led_3mm.png Blue 3mm water clear - 25deg - 7000mCd - x10 3.1 25 25 6000-8000 mCd (@20mA)
red_led_3mm.png Red 3mm water clear - 25deg - 12500mCd - x0 2.1 25 25 10000-15000 mCd (@20mA)
Description Forward voltage
drop typical (V)		 Viewing Angle Max forward
current (mA)		 Typical luminous
intensity
red_led_5mm.png Red super flux 5mm water clear LED - 80deg 1250mCd 1.9-2.3 80 20 1000-1500 mCd (@20mA)
yellow_led_5mm.png Yellow super flux 5mm water clear LED - 80deg - 1250 mCd 1.9-2.3 80 20 1000-1500 mCd (@20mA)
green_led_5mm.png Green super flux 5mm LED - 80deg - 1350mCd 2.9-3.5 80 20 1100-1600 mCd (@20mA)
blue_led_5mm.png Blue super flux 5mm LED - 80deg - 1350mCd 2.9-3.5 80 20 1100-1600 mCd (@20mA)
white_led_5mm.png White super flux 5mm water clear LED - 80deg - 1800mCd 2.9-3.5 80 20 1500-2100 mCd (@20mA)
Infrared 5mm water clear LED - 15deg - 1100mCd 1.7 15 20 1100 mCd (@20mA)
